Die folgende Tabelle bietet Ihnen einen Auszug der bevorrateten Güten und Ausführungen, welche den allgemein gültigen EN 10088 und DIN EN ISO 9445 entsprechen.
Werkstoff- nummer | Werkstoff- bezeichnung | AISI- Nummer | Analyse- Auszug | Blech | Ausführung | Band | Band / Blockguss | Ausführung |
---|---|---|---|---|---|---|---|---|
1.4016 | X6Cr17 | 430 | Cr 17% | ✓ | 2B, 2R | ✓ | 2H, 2R | |
1.4021 | X20Cr13 | 420 | C 0,20%, Cr 13% | ✓ | 2B, 1D/E | ✓ | ✓ | 2B |
1.4024 | X15Cr13 | 420 | C 0,15%, Cr 13% | ✓ | 2B | |||
1.4028 | X30Cr13 | 420 | C 0,30%, Cr 13% | ✓ | ✓ | 2B | ||
1.4034 | X46Cr13 | 420B | C 0,45%, Cr 13% | ✓ | 2B, 1D/E | ✓ | ✓ | 2B |
1.4110 | X55CrMo14 | 440 | C 0,50%, Cr 14-15%, Mo 0,60% | ✓ | 2B, 1D/E | ✓ | ✓ | 2B |
1.4109 | X70CrMo15 | 440A | C 0,70%, Cr 14-16%, Mo 0,60% | ✓ | 2B | |||
1.4112 | X90CrMoV18 | 440B | C 0,90%, Cr 17-19%, Mo 0,90% | ✓ | 1E | |||
1.4116 | X50CrMoV15 | 440 | C 0,50%, Cr 14-15%, Mo 0,60% | ✓ | 2B, 1D/E | ✓ | ✓ | 2B, 1E |
Nitro-B | X45CrMoVN15 | C 0,50%, Cr 14-15%, Mo 0,60%, N 0,15% | ✓ | 2B | ||||
1.4301 | X5CrNi18-10 | 304 | Cr 18%, Ni 8-10% | ✓ | 2B, 2R, 2H, 1D | ✓ | 2B, 2R, 2H | |
1.4310 | X10CrNi18-8 | 301 | Cr 18%, Ni 6-9,5%, Si 2%, Mn 2% | ✓ | 2H |
Werkstoff- nummer | Werkstoff- bezeichnung | AISI- Nummer | Analyse- Auszug | Rund | Flach | Konisch |
---|---|---|---|---|---|---|
1.4016 | X6Cr17 | 430 | Cr 17% | ✓ | ||
1.4021 | X20Cr13 | 420 | C 0,20%, Cr 13% | ✓ | ✓ | |
1.4028 | X30Cr13 | 420 | C 0,30%, Cr 13% | ✓ | ✓ | |
1.4034 | X46Cr13 | 420B | C 0,45%, Cr 13% | ✓ | ✓ | ✓ |
1.4057 | X17CrNi16-2 | 431 | C 0,17%, Cr 16%, Ni 2% | ✓ | ✓ | |
1.4109 | X70CrMo15 | 440A | C 0,60%, Cr 14-16%, Mo 0,60% | ✓ | ✓ | ✓ |
1.4110 | X55CrMo14 | 440 | C 0,50%, Cr 14-15%, Mo 0,60% | ✓ | ✓ | |
1.4112 | X90CrMoV18 | 440B | C 0,90%, Cr 17-19%, Mo 0,90% | ✓ | ✓ | |
1.4116 | X50CrMoV15 | 440 | C 0,50%, Cr 14-15%, Mo 0,60% | ✓ | ✓ | |
1.4117 | X38CrMoV15 | C 0,38%, Cr 14-15%, Mo 0,50% | ✓ | ✓ | ||
1.4125 | X105CrMo17 | 440C | C 1,1%, Cr 17%, Mo 0,60% | ✓ | ||
1.4301 | X5CrNi18-10 | 304 | Cr 18%, Ni 8-10% | ✓ | ||
1.4571 | X6CrNiMoTi17-12-2 | 316Ti | Cr 17,5%, Ni 12%, Mo 2% | ✓ |
